Place of Origin:
China
Brand Name:
SETON
Model Number:
CPR229
| Parameter | Value |
|---|---|
| Input Frequency | 3700 MHz ~ 4200 MHz |
| Output Frequency | 950 MHz ~ 1450 MHz |
| Noise figure | 30° K (Typ.)/50° K (Max.) |
| Phase noise @ 1 KHz | -75 dBc/Hz |
| Phase noise @ 10 KHz | -85 dBc/Hz |
| Phase noise @ 100 KHz | -95 dBc/Hz |
| Conversion Gain | 58 dB~68 dB/ 63dB (Typ.) |
| Gain Flatness | 5 dBp-p (Max.) |
| P1 dB | +10 dBm (Min.) |
| VSWR Input | 2.2:1 (Max.) |
| VSWR Output | 2.2:1 (Max.) |
| Local Oscillator | 5.15GHz |
| Local Oscillator Stability | ± 25 KHz |
| LNB Input Rejection | 50 dBc min.(@100MHz) |
| P1db (LNB Input 5G Power Level) | -30 dBm (Max.) |
| DC Power | +12 VDC - + 24 VDC |
| Input Connection | WR229G |
| Output Conector | F (75 Ω) / N(50Ω) |
| Current | 200mA (Max.) |
| Frequency Band(GHz) | 3.7~4.2 | 3.72~4.2 | 3.8~4.2 | 3.9~4.2 | 4.0~4.2 |
|---|---|---|---|---|---|
| L.O. Frequency(GHz) | 5.15 | 5.15 | 5.15 | 5.15 | 5.15 |
| IF Frequency(MHz) | 950~1450 | 950~1430 | 950~1350 | 950~1250 | 950~1150 |
