Place of Origin:
China
Brand Name:
SETON
Model Number:
KU WR75 ST-K11G
| Parameter | Value |
|---|---|
| Noise Figure | 0.5 dB (Typ.) 0.8dB (Max.) |
| L.O. Stability | ±50KHz |
| Phase Noise | -70dBc@1KHz; -80@10KHz; -90dBc@100KHz |
| Input VSWR | 2.2:1 |
| Output VSWR | 2.2:1 |
| Gain | 58~68dB/ 63dB (Typ.) |
| Gain Flatness(over full band) | 5dBp-p (Max.) |
| Output P1dB | +5dBm |
| DC Power | +12VDC~+24VDC |
| Tone | 22KHz±4 |
| Current | 250mA |
| Input Connection | WR75 |
| Output Connection | F(75Ω)/N(50Ω) |
| Anti-Thunder | 4KV(Min.)/6KV(Max.) |
| Rejection | KU-TI |
| Operating Temperature | -30℃~+60℃ |
| Storage Temperature | -40℃~+70℃ |
| Band 1 | Band 2 | Band 3 | Band 4 |
|---|---|---|---|
| 10.7~11.7 GHz | 10.95~11.7 GHz | 11.7~12.75 GHz | 12.25~12.75 GHz |
| L.O. 9.75 GHz | L.O. 10.00 GHz | L.O. 10.75 GHz | L.O. 11.30 GHz |
| IF 950~1950 MHz | IF 950~1700 MHz | IF 950~2000 MHz | IF 950~1450 MHz |
