Name: 3.7 - 4.2GHz Input Frequency C BAND 5G Filter 0.45dB Insertion Loss 60dBc Out Of Band Rejection
Brand: Chenzhou Seton Technology Co., Ltd
SKU: Anti-5G C-Band Filter
Availability: InStock

Home > Products > TVRO LNBF >

3.7 - 4.2GHz Input Frequency C BAND 5G Filter 0.45dB Insertion Loss 60dBc Out Of Band Rejection

4.2GHz C BAND 5G Filter

3.7GHz C BAND 5G Filter

5G C Band Filter 0.45dB

Place of Origin:

CHINA

Brand Name:

SETON

Certification:

CE, ISO, RoHS

Model Number:

Anti-5G C-Band Filter

Chat Now

Request A Quote

Product Details

Input Frequency(RF):

3.7 ~ 4.2/3.8 ~ 4.2/3.9 ~ 4.2/4.0 ~ 4.2GHz

Insertion Loss:

0.45dB[Max.]

Out-of-band Rejection (Guard Band=100MHz):

60dBc[Min.]

Output Connector:

WR229G/F

Highlight:

4.2GHz C BAND 5G Filter

3.7GHz C BAND 5G Filter

5G C Band Filter 0.45dB

Payment & Shipping Terms

Minimum Order Quantity

1pcs

Packaging Details

CARTON

Delivery Time

30-35 days

Payment Terms

T/T,Western Union

Universal Octo LNBF KU Band ST-K28H 10.7 - 12.75GHz Input Frequency

Chat Now

ST-K22Z KU BAND Universal LNBF Dual LO Frequency 9.75GHz 10.6GHz

Chat Now

ST-K21WD KU Band Single LNBF Universal 10.7 - 12.75GHz

Chat Now

Ku Band Universal Quad LNBF ST-K24HA 10.7 - 12.75GHz With 9.75 / 10.6GHz LO

Chat Now

86-0735-8888458

huang@setontech.cn

Chat Now

Product Description

C BAND 5G Filter Anti-5G Rejection-5G

Product Overview

The C BAND 5G Filter is designed for precise frequency control in 5G applications, featuring customizable frequency ranges and excellent rejection capabilities.

Key Features

LNB: 3.7~4.2 GHz (Customizable design according to different frequency requirements)
Guard Band: 100 MHz for enhanced signal isolation

Technical Specifications

Parameter	Specification
Input Frequency(RF)	3.7 ~ 4.2/3.8 ~ 4.2/3.9 ~ 4.2/4.0 ~ 4.2GHz
Insertion loss	0.45dB[Max.]
Out-of-band Rejection (Guard band=100MHz)	60dBc[Min.]
VSWR	2.2:1
Operating Temperature	-40 ~ +60℃
Output Connector	WR229G/F
